The TC2201 PCIe® Gen 4 NVMe™ DRAMless SSD Controller
The TC2201 is an industry-leading PCIe® Gen 4 NVMe™ DRAMless SSD controller designed to deliver outstanding performance of up to 7.3GB/s, reliability, and power efficiency for a wide range of small form factor computing applications.
Designed for Client Computing
APPLICATIONS
High-performance PCs
Laptops (Corporate)
FEATURE
TenaFe's technology breaks through barriers with its TC2201 DRAMless controller solution by offering impressive performance capabilities with leverage of Host Memory Buffer (HMB) feature that enables low power and cost effective BOM designs ideally for M.2 2280 SSD form factors.
Host Memory Buffer (HMB)
DATA INTEGRITY
Using FlexLDPC technology, an in-house developed advanced LDPC error correction engine, provides best in-class latency, quality of service (QoS), and endurance support for the latest TLC and QLC NAND Flash technologies.
FlexLDPC Technology
ARCHITECTURE
Solid State Drive (SSD) without on-board DRAM, is widely adopted across personal computer (PC) and embedded markets. As SSDs scale to multi-terabyte capacities, conventional SSD architecture that are dependent upon DRAM present challenges with respect to bill of material (BOM) costs, power consumption, thermals, and the increasing need to provide small form factor SSDs such as M.2 2230 and BGA. TenaFe’s technology breaks through barriers with its TC2200 DRAMless controller.
DRAMless
SPECIFICATIONS
Interface
DRAM
Power
• PCIe® Gen 4
• NVMe™ 1.4
• 4CH @ 2400 MT/s
• NAND Flash Support TLC & QLC
Flash
• DRAMless
• Support HMB
• Seq Read up to 7.4 GB/s
• Seq Write up to 7.0 GB/s
• Random 1M IOPS
Performance
• < 1.5mW Controller PS4
• < 4.5W SSD Active Power
• Inline AES-256, ECB
• Support TCG Standards
• FIPs 140-2 capable
• Secure Boot/Firmware Update
Security
• End-to-end data protection
• SRAM SECDED protection
• Advanced 4KB LDPC
• Plane-based/Die-based RAID
Data Integrity
