The TC2200 PCIe® Gen 4 NVMe™ DRAMless SSD Controller
The TC2200 is an industry leading PCIe® Gen 4 NVMe™ DRAMless SSD controller designed to deliver outstanding performance, reliability, and power efficiency for a wide range of small form factor computing applications.
APPLICATIONS
Designed for Client Technology
Gaming Consoles
Gaming Laptops/PCs
FEATURE
TenaFe's technology breaks through barriers with its TC2200 DRAMless controller solution by offering impressive performance capabilities of up to 4.8GB/s at less than 4.0W active power with leverage of Host Memory Buffer (HMB) feature that enables low power and cost effective BOM designs ideally for M.2 2280 SSD form factors.
Host Memory Buffer (HMB)
DATA INTEGRITY
Using FlexLDPC technology, an in-house developed advanced LDPC error correction engine, provides best in-class latency, quality of service (QoS), and endurance support for the latest TLC and QLC NAND Flash technologies.
FlexLDPC Technology
ARCHITECTURE
Solid State Drive (SSD) without on-board DRAM, is widely adopted across personal computer (PC) and embedded markets. As SSDs scale to multi-terabyte capacities, conventional SSD architecture that are dependent upon DRAM present challenges with respect to bill of material (BOM) costs, power consumption, thermals, and the increasing need to provide small form factor SSDs such as M.2 2230 and BGA. TenaFe’s technology breaks through barriers with its TC2200 DRAMless controller.
DRAMless
SPECIFICATIONS
Interface
Flash
DRAM
Performance
Power
Security
• 4CH @ 1600 MT/s
• NAND Flash Support TLC & QLC
• PCIe® Gen 4
• NVMe™ 1.4
• Seq Read up to 4.8 GB/s
• Seq Write up to 4.6 GB/s
• Random 550k IOPS
• DRAMless
• Support HMB
• Inline AES-256, ECB
• Support TCG Standards
• FIPs 140-2 capable
• Secure Boot/Firmware Update
• < 1.5mW Controller PS4
• < 4.5W SSD Active Power
Data Integrity
• End-to-end data protection
• SRAM SECDED protection
• Advanced 4KB LDPC
• Plane-based/Die-based RAID
